Investment Required
Rs 20 Lac- Rs 30 Lac
Combine Harvester GS 575
Last updated on
03 Feb 2019
Product added on
01 Feb 2019
We are
looking for distributors
Space Required
5000 sq ft
Brand
GOMSELMASH
Product Description
Gomselmash PALESSE GS575 â grain harvesting combine of «economy class» for small and medium-sized enterprises, which need compact and maneuverable technique. Classical thresher of 1200 mm width with big drum is reliable and unpretentious. Stable separation and high quality of grain are provided by use of four keys straw shaker and three stage separation. Single cabin of simple design with analog devices, which display data of automatic control system, provides quite fit working conditions. These are seat of enhanced comfort, air conditioner, good overview of header working area. Besides headers with 4 meters and 5 meters coverage width, provided modification of harvester, which can be equipped with 6 meters header for soya and cereal crops. Possibility of mounting of engines with different power allows to take into account wishes of farms with differences in acreage size and grain yield. Technical Specification: Engine Engine model Diesel MMZ D-260.1 Nominal engine power kW 114 Nominal engine power h.p. 155 Thresher Threshing drum typ drum-type Threshing drum width mm 1200 Threshing drum diameter mm 800 Shaft speed of threshing drum s-1 8.51...14.6 Number ofbeater plates 10 Concave typ cancellated, adjustable Concave area m2 1.1 Rear beater Diameter mm 400 Rotation frequency s-1 13.1 Straw walker Separation area, not less than m2 4.92 Length of straw walker key mm 4100 Separation Total sieve area, not less than m2 3.86 Maximum opening of deflectors mm 20 Shaft speed of fan ventilator s-1 5.3...16.5 Grain tank Grain tank volume, not less than m3 3.5 Rotation frequency of unloading auger s-1 10.9 Undercarriage Wheel base mm 3366+50 Road clearance mm 300 Minimum inside turning radius m 7.5 Fuel tank volume 300L. Operating speed km/h 8 Road speed km/h 20 Overall dimensions and weight Dimensions of standard set in operating position, up to: - length mm 10600 - width mm 4400 - height mm 4000 Length /Width/Height in transport position mm 8300 / 3720 / 4000 Weight of the thresher kg 10000
